How to Use Old Lenses and Speed Boosters With Your New Camera

By Jason Row / October 3, 2015

There are some amazing lenses out there. Beautiful, fast and sharp. The interesting thing is that not all of them are brand new or even designed for digital cameras. For those of you who love to work manually there is an entire world of brilliant secondhand lenses that you can attach to your modern camera. There is another interesting element to this as well. As you will imagine, to put an old lens on a new camera you need an adapter. This will convert the mount on the old lens, to the mount on the new camera body. The most common of these are simple rings with no optical elements and more often than not, no electronic connection. There is however another class of adapter, that has some rather useful properties. They are called speed boosters and today we are going to take a look at what they are, what they do and why you should buy one and some older lenses.

Old onto new goes. A Canon FD 50mm on a Modern Mirrorless Camera, by Conal Gallagher

It started with Metabones. One of the biggest issues with smaller sensor cameras is the crop factor. For an APS camera this is around 1.5X, for a 4/3 or Micro 4/3 it is 2X. The issue here is that wide angle lenses become significantly less wide when you factor in the crop. Metabones realised this and also realised that there was demand to use lenses from different manufacturers on new cameras. They came up with the speedbooster adaptors.

These adapters would not only convert lenses to cameras but due to a series of optical elements inside, they would also reduce the crop factor. When you put an old 50mm f1.8 lens on a Micro 4/3rds camera, the field of view of that lens would change to an equivalent of 100mm. In other words 2X the original focal length. By using the SpeedBooster, that crop factor came down to around 1.7X so that 50mm lens was now only a 70mm.

There was one other, huge advantage to this, the aperture. Many of us have used tele-convertors before and we know that adding a 2X converter will reduce your lens’s widest aperture by 2 stops. Speedboosters do this in reverse. Because they focus the light from all parts of the lens to cover the entire sensor, they actually increase the maximum aperture. That 50mm f1.8 lens is now a 70mm, f1.4 with the associated  decrease in depth of field.

Speed Boosters can give you an extra stop of aperture. Useful on smaller sensors. By Bernhard Friess

The main problem with the Metabones' original Speedboosters was their price. At $300-$400 for a convertor, it was often better just to buy the widest fast lens that the manufacturer offered. However, as with many things tech based, other companies, often but not exclusively Chinese, have stepped up and produced similar products for much cheaper prices. Often the quality of these are as good, if not better than the original for a fraction of the price. Now, it is possible to add some spectacularly good glass to a Speedbooster for a very low cost.

How a Speed Booster Works by tenz1225

Why Buy Old Lenses?

The simple answer to this, is that you will bag a bargain. The best bargains out there are for old Nikon AI lenses and also Canon FD lenses. The Nikons tend to be a bit more expensive as they can still be used on current Nikon cameras without an adapter. However, when Canon made the move the EOS range back in the early 1990’s they abandoned the old FD mount. This mount was used on a range of excellent lenses used for both pro and consumer cameras. A quick look through eBay will reveal a plethora of FD lenses for very cheap prices. I recently picked up a 28mm f2.8 for £25 and a 135mm f3.5 for £30. Both in mint condition and capable of stunning images.

If you are prepared to work, you can get stunning lenses for next to nothing. By s58y

What are the Disadvantages?

What ever way you attach an old lens to a new camera, the chances are you will not have electronic aperture control or auto focus. Older lenses are ironically best suited to newer mirrorless cameras. The reason for this is that because you have to manually stop down the lens aperture, mirrorless cameras will compensate the amount of light coming through the viewfinder making the image still seem bright to the eye. In a DSLR, because the viewfinder is optical, as you stop down,  less light reaches your eye.

Mirrorless cameras also have electronic focusing aids such as peaking and live zoom to help you get perfect manual focus with that old lens. Old lenses take a little bit of work but with some practice, you can get some stunning images.

The combination of adaptors or SpeedBoosters and old lenses can not only increase the range of optics you can use for a low price but in the case of Speedboosters also reduce crop factor and improve the maximum aperture of that lens. In other words its a win win.


s

About the author

Jason Row

Jason Row is a British born travel photographer now living in Ukraine. His images have been licensed to companies such as Cunard, Ethiad and Virgin Atlantic as well as multiple newspapers and magazines. As well as shooting stills he is now creating travel stock video in 4K. He maintains a travel stock photography site at Jason Row Photography You can also catch up with him on Instagram at Jason Row Photography

  • Mike says:

    Very interesting article, thanks. I have a Sony a6000 & recently acquired 2 old Canon FD lenses (35mm & 50mm) & I need an adaptor or Speedbooster to get them to work together. Where can I get one? Your recommendations &/ or comments would be appreciated.
    Many thanks

  • Mae says:

    Very interesting article. Can you please list some of the high quality alternatives to the Metabones Speedbooster?

  • Paul Glass-Steel says:

    I’ve had a Metabones Speed Booster more or less welded to my Fuji X-E1 for over a year now. Before I bought it, I tried three Chinese knockoffs. There is no question, in my experience, that the Metabones product is vastly superior optically and mechanically. One of the knock-offs was so bad, it could not focus a 50mm lens past 10 feet. I’m not associated with Metabones, just a big fan of this method of shooting.

    One tip: if you get a speed booster for Canon FD mount, you can also use M42 and Nikon F mount lenes with additional, cheap non-optical ring adapters.

    • Kenny Z says:

      I have a Chinese FD-43 knock off for my OMD EM5 and I find that if your infinity focus is off you can manually adjust the optical element to find your infinity by turning the focal reducing element in its thread. That solved my issues for infinity being off the mark and increases your range of focus to the correct throw. It just takes a bit of back and forth play and firing test shots to confirm that the lens is at its infinite focus. Once you find it you can apply some low strength thread locker on the rim and that will more of less settle it in place. Just be careful not to smear the thread locker fluid on the optics and let it sit overnight to cure. I hope this helps as I enjoy using vintage lenses on my OMD and I’m also looking into getting a FD to Xmount when i decide to jump to Fuji.

  • Ed says:

    On a MFT camera body – if the speedbooster reduces the crop factor to 1.7 shouldn’t the full frame equivalent for the 50mm lens be 85mm (as opposed to the 70mm stated in the article?

  • Carla says:

    I have several ON and Zukio lenses. Wondering which new camera would be best adaptability? Just correcting spelling.
